INA KWVE20-B-ESC-V1-G4 Rulman
Fiyatı: 1,953.37 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-ESC-V1-G4 INA |
| Üretici No | 0125089500250 |
| Alternatif Kodu |
KWVE20-B-ESC-G4-V1 |
| EAN | 4054362968221 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 42 |
| En (B) MM | 50,4 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 1.6535 |
| En (B) Inch | 1.9843 |
| Ağırlık | 0.18 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 42 |
| Overall length carriage (L) mm | 50,4 |
| Dynamic load rating (C) | 8900 |
| Static load rating (C 0) | 15400 |
| Static moment rating about X axis (M 0x) | 190 |
| Static moment rating about Y axis (M 0y) | 85 |
| Static moment rating about Z axis (M 0z) | 85 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| V1 | Slight Preload |
| G4 | Precision Class 4 |
