INA KWVE20-B-L-V1-G2 Rulman
Fiyatı: 3,445.42 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-L-V1-G2 INA |
| Üretici No | 0125089000230 |
| Alternatif Kodu |
KWVE20-B-L-G2-V1 |
| EAN | 4054362970705 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 63 |
| En (B) MM | 88,9 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.4803 |
| En (B) Inch | 3.5 |
| Ağırlık | 0.59 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 63 |
| Overall length carriage (L) mm | 88,9 |
| Dynamic load rating (C) | 16200 |
| Static load rating (C 0) | 36500 |
| Static moment rating about X axis (M 0x) | 452 |
| Static moment rating about Y axis (M 0y) | 430 |
| Static moment rating about Z axis (M 0z) | 430 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-L, long carriage, four-row, full complement ball set |
| B | Version |
| L | Long Carriage |
| V1 | Slight Preload |
| G2 | Precision Class 2 |
