INA KWVE20-WL-V2-G3 Rulman
Fiyatı: 3,930.69 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-WL-V2-G3 INA |
| Üretici No | 0665880650340 |
| Alternatif Kodu |
KWVE20-WL-G3-V2 |
| EAN | 4054364593810 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 42 |
| Dış (D) MM | 80 |
| En (B) MM | 87,3 |
| İç (d) Inch | 1.6535 |
| Dış (D) Inch | 3.1496 |
| En (B) Inch | 3.437 |
| Ağırlık | 0.7 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 80 |
| Overall length carriage (L) mm | 87,3 |
| Dynamic load rating (C) | 16200 |
| Static load rating (C 0) | 36500 |
| Static moment rating about X axis (M 0x) | 920 |
| Static moment rating about Y axis (M 0y) | 400 |
| Static moment rating about Z axis (M 0z) | 400 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly |
| WL | Wide, Long Carriage |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
