INA KWVE25-B-EC-V2-G1 Rulman
Fiyatı: 2,362.10 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-B-EC-V2-G1 INA |
| Üretici No | 0116944590320 |
| Alternatif Kodu |
KWVE25-B-EC-G1-V2 |
| EAN | 4054362978831 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 73 |
| En (B) MM | 58,2 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 2.874 |
| En (B) Inch | 2.2913 |
| Ağırlık | 0.4 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 73 |
| Overall length carriage (L) mm | 58,2 |
| Dynamic load rating (C) | 12500 |
| Static load rating (C 0) | 22200 |
| Static moment rating about X axis (M 0x) | 305 |
| Static moment rating about Y axis (M 0y) | 155 |
| Static moment rating about Z axis (M 0z) | 155 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row |
| B | Version |
| EC | Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| V2 | Preload Class 2 |
| G1 | Precision Class 1 |
