INA KWVE25-B-ES-UG-V0-G1 Rulman

Özellikler

Marka	INA
Ürün No	KWVE25-B-ES-UG-V0-G1 INA
Üretici No	0605502950120
Alternatif Kodu	KWVE25-B-ES-UG-G1-V0
EAN	4054362980476
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	23
Dış (D) MM	48
İç (d) Inch	0.9055
Dış (D) Inch	1.8898
Ağırlık	0.522 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	48
Overall length carriage (L) mm	83,3
Dynamic load rating (C)	17900
Static load rating (C 0)	37000
Static moment rating about X axis (M 0x)	510
Static moment rating about Y axis (M 0y)	395
Static moment rating about Z axis (M 0z)	395
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-ES, carriage for four-row linear ball bearing and guideway assembly, expanded type, narrow design

Suffix description

B	Version
ES	Expanded Design, Narrow Carriage
UG	Un-Greased
V0	Little To No Preload
G1	Precision Class 1
