INA KWVE25-B-ESC-V1-G2 Rulman

Özellikler

Marka	INA
Ürün No	KWVE25-B-ESC-V1-G2 INA
Üretici No	0116942110230
Alternatif Kodu	KWVE25-B-ESC-G2-V1
EAN	4054362979760
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	23
Dış (D) MM	48
En (B) MM	58,2
İç (d) Inch	0.9055
Dış (D) Inch	1.8898
En (B) Inch	2.2913
Ağırlık	0.3 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	48
Overall length carriage (L) mm	58,2
Dynamic load rating (C)	12500
Static load rating (C 0)	22200
Static moment rating about X axis (M 0x)	305
Static moment rating about Y axis (M 0y)	155
Static moment rating about Z axis (M 0z)	155
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set

Suffix description

B	Version
ESC	Expanded Design, Short, Narrow Carriage
V1	Slight Preload
G2	Precision Class 2
