INA KWVE30-B-EC-RROC-V2-G3 Rulman
Fiyatı: 3,410.66 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-B-EC-RROC-V2-G3 INA |
| Üretici No | 0782587820340 |
| EAN | 4054362993636 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| Dış (D) MM | 90 |
| En (B) MM | 69 |
| İç (d) Inch | 1.1024 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 2.7165 |
| Ağırlık | 0.75 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 69 |
| Dynamic load rating (C) | 18700 |
| Static load rating (C 0) | 31500 |
| Static moment rating about X axis (M 0x) | 554 |
| Static moment rating about Y axis (M 0y) | 248 |
| Static moment rating about Z axis (M 0z) | 248 |
| B | Version |
| EC | Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| RROC | Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
