INA KWVE30-B-L-V1-G3 Rulman
Fiyatı: 4,099.66 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-B-L-V1-G3 INA |
| Üretici No | 0171747160240 |
| Alternatif Kodu |
KWVE30-B-L-G3-V1 |
| EAN | 4054362997849 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| Dış (D) MM | 90 |
| En (B) MM | 127 |
| İç (d) Inch | 1.1024 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 5 |
| Ağırlık | 1.7 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 127 |
| Dynamic load rating (C) | 34500 |
| Static load rating (C 0) | 74000 |
| Static moment rating about X axis (M 0x) | 1310 |
| Static moment rating about Y axis (M 0y) | 1240 |
| Static moment rating about Z axis (M 0z) | 1240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-L, long carriage, four-row, full complement ball set |
| B | Version |
| L | Long Carriage |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
