INA KWVE30-W-V2-G2 Rulman
Fiyatı: 4,303.60 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-W-V2-G2 INA |
| Üretici No | 0213141100330 |
| Alternatif Kodu |
KWVE30-W-G2-V2 |
| EAN | 4054366349002 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 80 |
| Dış (D) MM | 142 |
| En (B) MM | 97,6 |
| İç (d) Inch | 3.1496 |
| Dış (D) Inch | 5.5906 |
| En (B) Inch | 3.8425 |
| Ağırlık | 1.95 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 142 |
| Overall length carriage (L) mm | 97,5 |
| Dynamic load rating (C) | 27500 |
| Static load rating (C 0) | 55000 |
| Static moment rating about X axis (M 0x) | 2660 |
| Static moment rating about Y axis (M 0y) | 700 |
| Static moment rating about Z axis (M 0z) | 700 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly |
| W | Wide Carriage |
| V2 | Preload Class 2 |
| G2 | Precision Class 2 |
