INA KWVE35-B-EC-V1-G4 Rulman

Özellikler

Marka	INA
Ürün No	KWVE35-B-EC-V1-G4 INA
Üretici No	0200582760250
Alternatif Kodu	KWVE35-B-EC-G4-V1
EAN	4054366341648
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	100
En (B) MM	76,2
İç (d) Inch	1.3386
Dış (D) Inch	3.937
En (B) Inch	3
Ağırlık	1.04 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	100
Overall length carriage (L) mm	76,2
Dynamic load rating (C)	24600
Static load rating (C 0)	39000
Static moment rating about X axis (M 0x)	790
Static moment rating about Y axis (M 0y)	330
Static moment rating about Z axis (M 0z)	330
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row

Suffix description

B	Version
EC	Expanded Design, Short Carriage (Carriage Without Screw Threads)
V1	Slight Preload
G4	Precision Class 4
