INA KWVE35-B-NL-V2-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWVE35-B-NL-V2-G3 INA
Üretici No	0200410120340
Alternatif Kodu	KWVE35-B-NL-G3-V2
EAN	4054366339782
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	100
En (B) MM	145
İç (d) Inch	1.3386
Dış (D) Inch	3.937
En (B) Inch	5.7087
Ağırlık	2.23 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	100
Overall length carriage (L) mm	145
Dynamic load rating (C)	47500
Static load rating (C 0)	100000
Static moment rating about X axis (M 0x)	2625
Static moment rating about Y axis (M 0y)	1890
Static moment rating about Z axis (M 0z)	1890
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-NL, low, long carriage, four-row

Suffix description

B	Version
NL	Low, Long Carriage
V2	Preload Class 2
G3	Precision Class 3
