INA KWVE35-B-SNL-RROC-V2-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWVE35-B-SNL-RROC-V2-G3 INA
Üretici No	0782393200340
EAN	4054366883162
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	70
En (B) MM	145
İç (d) Inch	1.3386
Dış (D) Inch	2.7559
En (B) Inch	5.7087
Ağırlık	1.72 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	70
Overall length carriage (L) mm	145
Dynamic load rating (C)	47500
Static load rating (C 0)	100000
Static moment rating about X axis (M 0x)	2625
Static moment rating about Y axis (M 0y)	1890
Static moment rating about Z axis (M 0z)	1890

Suffix description

B	Version
SNL	Narrow, Low, Long Carriage
RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2	Preload Class 2
G3	Precision Class 3
