INA KWVE35-B-SNL-V1-G2 Rulman
Fiyatı: 4,326.71 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-SNL-V1-G2 INA |
| Üretici No | 0200516970230 |
| Alternatif Kodu |
KWVE35-B-SNL-G2-V1 |
| EAN | 4054366340115 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 70 |
| En (B) MM | 145 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 2.7559 |
| En (B) Inch | 5.7087 |
| Ağırlık | 1.72 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 70 |
| Overall length carriage (L) mm | 145 |
| Dynamic load rating (C) | 47500 |
| Static load rating (C 0) | 100000 |
| Static moment rating about X axis (M 0x) | 2625 |
| Static moment rating about Y axis (M 0y) | 1890 |
| Static moment rating about Z axis (M 0z) | 1890 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-SNL, narrow, low, long carriage, four-row |
| B | Version |
| SNL | Narrow, Low, Long Carriage |
| V1 | Slight Preload |
| G2 | Precision Class 2 |
