INA KWVE35-WL-V0-G2 Rulman
Fiyatı: 5,394.13 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-WL-V0-G2 INA |
| Üretici No | 0328805960130 |
| Alternatif Kodu |
KWVE35-WL-G2-V0 |
| EAN | 4054366357281 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 90 |
| Dış (D) MM | 162 |
| En (B) MM | 140,2 |
| İç (d) Inch | 3.5433 |
| Dış (D) Inch | 6.378 |
| En (B) Inch | 5.5197 |
| Ağırlık | 4.11 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 162 |
| Overall length carriage (L) mm | 140,2 |
| Dynamic load rating (C) | 47500 |
| Static load rating (C 0) | 100000 |
| Static moment rating about X axis (M 0x) | 5550 |
| Static moment rating about Y axis (M 0y) | 1890 |
| Static moment rating about Z axis (M 0z) | 1890 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly |
| WL | Wide, Long Carriage |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
