INA KWVE45-B-ESC-V0-G3 Rulman
Fiyatı: 3,440.76 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE45-B-ESC-V0-G3 INA |
| Üretici No | 0180750960140 |
| Alternatif Kodu |
KWVE45-B-ESC-G3-V0 |
| EAN | 4054366330345 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 45 |
| Dış (D) MM | 86 |
| En (B) MM | 97,8 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 3.3858 |
| En (B) Inch | 3.8504 |
| Ağırlık | 1.8 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 86 |
| Overall length carriage (L) mm | 97,8 |
| Dynamic load rating (C) | 46500 |
| Static load rating (C 0) | 80000 |
| Static moment rating about X axis (M 0x) | 2060 |
| Static moment rating about Y axis (M 0y) | 883 |
| Static moment rating about Z axis (M 0z) | 883 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| V0 | Little To No Preload |
| G3 | Precision Class 3 |
