INA KWVE45-B-H-V2-G1 Rulman
Fiyatı: 4,485.92 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE45-B-H-V2-G1 INA |
| Üretici No | 0200702680320 |
| Alternatif Kodu |
KWVE45-B-H-G1-V2 |
| EAN | 4054366342188 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 45 |
| Dış (D) MM | 86 |
| En (B) MM | 140,6 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 3.3858 |
| En (B) Inch | 5.5354 |
| Ağırlık | 3.36 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 86 |
| Overall length carriage (L) mm | 140,6 |
| Dynamic load rating (C) | 69000 |
| Static load rating (C 0) | 141000 |
| Static moment rating about X axis (M 0x) | 3610 |
| Static moment rating about Y axis (M 0y) | 2485 |
| Static moment rating about Z axis (M 0z) | 2485 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-H, high, narrow carriage, four-row |
| B | Version |
| H | High Carriage |
| V2 | Preload Class 2 |
| G1 | Precision Class 1 |
