INA KWVE45-B-NL-V0-G4 Rulman
Fiyatı: 5,110.47 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE45-B-NL-V0-G4 INA |
| Üretici No | 0201053390150 |
| Alternatif Kodu |
KWVE45-B-NL-G4-V0 |
| EAN | 4054364007225 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 45 |
| Dış (D) MM | 120 |
| En (B) MM | 172,7 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 4.7244 |
| En (B) Inch | 6.7992 |
| Ağırlık | 3.38 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 120 |
| Overall length carriage (L) mm | 172,7 |
| Dynamic load rating (C) | 82000 |
| Static load rating (C 0) | 181000 |
| Static moment rating about X axis (M 0x) | 4635 |
| Static moment rating about Y axis (M 0y) | 4000 |
| Static moment rating about Z axis (M 0z) | 4000 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-NL, low, long carriage, four-row |
| B | Version |
| NL | Low, Long Carriage |
| V0 | Little To No Preload |
| G4 | Precision Class 4 |
