INA KWVE45-B-V2-G4 Rulman
Fiyatı: 4,088.42 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE45-B-V2-G4 INA |
| Üretici No | 0180750610350 |
| Alternatif Kodu |
KWVE45-B-G4-V2 |
| EAN | 4054366329745 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 45 |
| Dış (D) MM | 120 |
| En (B) MM | 140,6 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 4.7244 |
| En (B) Inch | 5.5354 |
| Ağırlık | 3.3 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 120 |
| Overall length carriage (L) mm | 140,6 |
| Dynamic load rating (C) | 69000 |
| Static load rating (C 0) | 141000 |
| Static moment rating about X axis (M 0x) | 3610 |
| Static moment rating about Y axis (M 0y) | 2485 |
| Static moment rating about Z axis (M 0z) | 2485 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B, standard carriage, four-row, full complement ball set |
| B | Version |
| V2 | Preload Class 2 |
| G4 | Precision Class 4 |
