INA KWVE55-B-S-RROC-V1-G3 Rulman

Özellikler

Marka	INA
Ürün No	KWVE55-B-S-RROC-V1-G3 INA
Üretici No	0782127740240
Alternatif Kodu	KWVE55-B-S-RROC-G3-V1
EAN	4054364011277
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	53
Dış (D) MM	100
En (B) MM	173,6
İç (d) Inch	2.0866
Dış (D) Inch	3.937
En (B) Inch	6.8346
Ağırlık	4.35 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	100
Overall length carriage (L) mm	173,6
Dynamic load rating (C)	104000
Static load rating (C 0)	213000
Static moment rating about X axis (M 0x)	5600
Static moment rating about Y axis (M 0y)	2730
Static moment rating about Z axis (M 0z)	2730
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-S, narrow carriage, four-row

Suffix description

B	Version
S	Narrow Carriage
RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V1	Slight Preload
G3	Precision Class 3
