INA KWVE55-B-S-V2-G3 Rulman
Fiyatı: 8,789.52 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE55-B-S-V2-G3 INA |
| Üretici No | 0202244350340 |
| Alternatif Kodu |
KWVE55-B-S-G3-V2 |
| EAN | 4054366346599 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 53 |
| Dış (D) MM | 100 |
| En (B) MM | 173,6 |
| İç (d) Inch | 2.0866 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 6.8346 |
| Ağırlık | 4.35 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 173,6 |
| Dynamic load rating (C) | 104000 |
| Static load rating (C 0) | 213000 |
| Static moment rating about X axis (M 0x) | 5600 |
| Static moment rating about Y axis (M 0y) | 2730 |
| Static moment rating about Z axis (M 0z) | 2730 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-S, narrow carriage, four-row |
| B | Version |
| S | Narrow Carriage |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
