INA LR50/5-2RSR-HLC Rulman

Özellikler

Marka	INA
Ürün No	LR50/5-2RSR-HLC INA
Üretici No	0004291550000
EAN	4054364591106
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	5
Dış (D) MM	17
En (B) MM	7
İç (d) Inch	0.1969
Dış (D) Inch	0.6693
En (B) Inch	0.2756
Ağırlık	0.01 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Height (C) mm	7
Basic dynamic load rating, radial (C r w)	1690
Temel statik yük derecesi, radyal (C 0r)	950
Speed on permanent grease lubrication (n D G)	12000
ECLASS number	23-05-15-90
ECLASS2 number	23-05-15-90
Medias description	Track rollers LR50, double row, sealed on both sides

Suffix description

2RSR	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
HLC	Factory Location Code, No Additional Meaning, Can Be Used As Standard
