INA LR50/7-2RS-HLC Rulman

Özellikler

Marka	INA
Ürün No	LR50/7-2RS-HLC INA
Üretici No	0004296600000
EAN	4054364591083
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	7
Dış (D) MM	22
En (B) MM	10
İç (d) Inch	0.2756
Dış (D) Inch	0.8661
En (B) Inch	0.3937
Ağırlık	0.02 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Height (C) mm	10
Basic dynamic load rating, radial (C r w)	3300
Temel statik yük derecesi, radyal (C 0r)	1700
Speed on permanent grease lubrication (n D G)	10000
ECLASS number	23-05-15-90
ECLASS2 number	23-05-15-90
Medias description	Track rollers LR50, double row, sealed on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
HLC	Factory Location Code, No Additional Meaning, Can Be Used As Standard
