INA LR5304-2HRS-TVH-XL Rulman

Özellikler

Marka	INA
Ürün No	LR5304-2HRS-TVH-XL INA
Üretici No	0838744100000
Alternatif Kodu	LR5304-2HRS-TVH
EAN	4054369265088
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	62
En (B) MM	22,2
İç (d) Inch	0.7874
Dış (D) Inch	2.4409
En (B) Inch	0.874
Ağırlık	0.34 kg

Ürün Özellikleri

Fok	2RH - İki Tarafta Yüksek Hızlı Düşük Sürtünmeli Conta
Running Surface	Standard

Data from Schaeffler (medias)

Height (C) mm	22,2
Basic dynamic load rating, radial (C r w)	22200
Temel statik yük derecesi, radyal (C 0r)	17200
Speed on permanent grease lubrication (n D G)	4850
ECLASS number	23-05-15-90
ECLASS2 number	23-05-15-90
Medias description	Track roller LR..-2HRS-TVH-XL, two-row, no plastic tyre

Suffix description

2HRS	Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
TVH	Moulded Polyamide Cage Snap-Type, Rolling Element Riding
XL	X-Life
