INA PWKRE90-2RS-RR-XL Rulman

Özellikler

Marka	INA
Ürün No	PWKRE90-2RS-RR-XL INA
Üretici No	0645872660000
Alternatif Kodu	PWKRE90-2RS-RR
EAN	4054366813206
Kategori	Kam Takipçisi

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	90
En (B) MM	35
İç (d) Inch	1.378
Dış (D) Inch	3.5433
En (B) Inch	1.378
Ağırlık	2.186 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Excenterring	E - Excenterring with Inbus Mount
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	30
Genişlik (b) mm	100
Basic dynamic load rating, radial (C r w)	63000
Temel statik yük derecesi, radyal (C 0r)	89000
Speed on permanent grease lubrication (n D G)	1800
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Yoke type track roller PWKRE..-2RS-RR-XL, full complement roller set, two-row, with axial guidance, with eccentric, pallet changer

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103
RR	Protected Against Corrosion By Corrotect® Special Coating
XL	X-Life
