INA PWTR20-2RS-XL Rulman

Özellikler

Marka	INA
Ürün No	PWTR20-2RS-XL INA
Üretici No	0638157530000
Alternatif Kodu	PWTR20-2RS
EAN	4012802844719
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	20
Dış (D) MM	47
En (B) MM	24
İç (d) Inch	0.7874
Dış (D) Inch	1.8504
En (B) Inch	0.9449
Ağırlık	0.245 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Width inner ring (B) mm	25
Basic dynamic load rating, radial (C r w)	24400
Temel statik yük derecesi, radyal (C 0r)	31000
Speed on permanent grease lubrication (n D G)	3800
ECLASS number	23-05-15-01
ECLASS2 number	23-05-15-01
Medias description	Yoke type track rollers PWTR..-2RS, full complement cylindrical roller set, with axial guidance, lip seals on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
XL	X-Life
