INA PWTR3580-2RS-XL Rulman

Özellikler

Marka	INA
Ürün No	PWTR3580-2RS-XL INA
Üretici No	0645546190000
Alternatif Kodu	PWTR3580-2RS
EAN	4047643212083
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	35
Dış (D) MM	80
En (B) MM	28
İç (d) Inch	1.378
Dış (D) Inch	3.1496
En (B) Inch	1.1024
Ağırlık	0.836 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Width inner ring (B) mm	29
Basic dynamic load rating, radial (C r w)	43500
Temel statik yük derecesi, radyal (C 0r)	62000
Speed on permanent grease lubrication (n D G)	1800
ECLASS number	23-05-15-01
ECLASS2 number	23-05-15-01
Medias description	Yoke type track rollers PWTR..-2RS, full complement cylindrical roller set, with axial guidance, lip seals on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
XL	X-Life
