INA PWTR4090-2RS-XL Rulman

Özellikler

Marka	INA
Ürün No	PWTR4090-2RS-XL INA
Üretici No	0645549530000
Alternatif Kodu	PWTR4090-2RS
EAN	4047643212021
Kategori	Destek Silindiri

Ağırlık ve Boyutlar

İç (d) MM	40
Dış (D) MM	90
En (B) MM	30
İç (d) Inch	1.5748
Dış (D) Inch	3.5433
En (B) Inch	1.1811
Ağırlık	1.129 kg

Ürün Özellikleri

Fok	2RS - İki Tarafta Kauçuk Conta
Running Surface	Standard

Data from Schaeffler (medias)

Width inner ring (B) mm	32
Basic dynamic load rating, radial (C r w)	53000
Temel statik yük derecesi, radyal (C 0r)	74000
Speed on permanent grease lubrication (n D G)	1500
ECLASS number	23-05-15-01
ECLASS2 number	23-05-15-01
Medias description	Yoke type track rollers PWTR..-2RS, full complement cylindrical roller set, with axial guidance, lip seals on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
XL	X-Life
