INA RWU35-E-V3-G2 Rulman
Fiyatı: 5,864.98 ₺
Özellikler
| Marka | INA |
| Ürün No | RWU35-E-V3-G2 INA |
| Alternatif Kodu |
RWU35-E-G2-V3 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 100 |
| En (B) MM | 122,9 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 4.8386 |
| Ağırlık | 1.75 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 122,9 |
| Dynamic load rating (C) | 59000 |
| Dynamic load rating (C 0) | 140000 |
| Static moment rating about X axis (M 0x) | 1200 |
| Static moment rating about Y axis (M 0y) | 2150 |
| Static moment rating about Z axis (M 0z) | 1950 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Standard carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication |
| E | Version |
| V3 | Preload Class 3 |
| G2 | Precision Class 2 |
