INA VSA201094-N-VSP-ZT Rulman
Fiyatı: 0.00 ₺
Özellikler
| Marka | INA |
| Ürün No | VSA201094-N-VSP-ZT INA |
| Üretici No | 0551602390000 |
| EAN | 4054366745576 |
| Kategori | Döndürme |
| Ağırlık | 91 kg |
| Fok | 2L - Her İki Tarafta LS Contası |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Split Inner ring / Outer ring | Standard |
| Outside Diameter (D a) mm | 1198,1 |
| ECLASS number | 23-05-14-90 |
| ECLASS2 number | 23-05-14-90 |
| N | Normalized Gear Teeth On Bearing Ring |
| VSP | For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary |
| ZT | Centring On Inner And Outer Rings |
