INA GAL12-UK Rulman Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 746.45 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
12 |
| Dış (D) MM |
34 |
| En (B) MM |
10 |
| İç (d) Inch |
0.4724 |
| Dış (D) Inch |
1.3386 |
| En (B) Inch |
0.3937 |
| Ağırlık |
0.065 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
22 |
| Outer eye diameter (d 2) mm |
34 |
| Radial Static Load Rating C0r (N) |
30200 |
| Width inner ring (B) mm |
10 |
| Radial Dynamic Load Rating Cr (N) |
11300 |
| Temel statik yük derecesi, radyal (C 0r) |
"30200.0000" |
| Total length external thread rod (l 2) mm |
71 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
