INA GE110-FW-2RS-B Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 43,424.38 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
110 |
| Dış (D) MM |
180 |
| En (B) MM |
100 |
| İç (d) Inch |
4.3307 |
| Dış (D) Inch |
7.0866 |
| En (B) Inch |
3.937 |
| Ağırlık |
9.8 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
180 |
| Radial Static Load Rating C0r (N) |
4480000 |
| Width inner ring (B) mm |
100 |
| Radial Dynamic Load Rating Cr (N) |
2690000 |
| Temel statik yük derecesi, radyal (C 0r) |
"4480000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series G, sealed |
Suffix description
| FW |
Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
| 2RS |
Lip Seals On Both Sides |
| B |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
