INA GE120-FO-2RS-A Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 48,838.65 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
120 |
| Dış (D) MM |
210 |
| En (B) MM |
115 |
| İç (d) Inch |
4.7244 |
| Dış (D) Inch |
8.2677 |
| En (B) Inch |
4.5276 |
| Ağırlık |
15 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
210 |
| Radial Static Load Rating C0r (N) |
5360000 |
| Width inner ring (B) mm |
115 |
| Radial Dynamic Load Rating Cr (N) |
1070000 |
| Temel statik yük derecesi, radyal (C 0r) |
"5250000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series G, sealed |
Suffix description
| FO |
Sliding Contact Surface Steel/Steel, Wider Inner Ring |
| 2RS |
Lip Seals On Both Sides |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
