INA GE120-SW-A Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 18,094.41 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
120 |
| Dış (D) MM |
180 |
| En (B) MM |
38 |
| İç (d) Inch |
4.7244 |
| Dış (D) Inch |
7.0866 |
| En (B) Inch |
1.4961 |
| Ağırlık |
3.73 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
180 |
| Height (T) mm |
38 |
| Radial Static Load Rating C0r (N) |
2490000 |
| Width inner ring (B) mm |
36 |
| Radial Dynamic Load Rating Cr (N) |
1500000 |
| Temel statik yük derecesi, radyal (C 0r) |
"2490000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
Suffix description
| SW |
Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
