INA GE160-DO-C3 Rulman Resim 6
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 26,038.90 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
160 |
| Dış (D) MM |
230 |
| En (B) MM |
105 |
| İç (d) Inch |
6.2992 |
| Dış (D) Inch |
9.0551 |
| En (B) Inch |
4.1339 |
| Ağırlık |
13.8 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
230 |
| Radial Static Load Rating C0r (N) |
6800000 |
| Width inner ring (B) mm |
105 |
| Radial Dynamic Load Rating Cr (N) |
1360000 |
| Temel statik yük derecesi, radyal (C 0r) |
"6660000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, open design |
Suffix description
| DO |
Sliding Contact Surface Steel/Steel |
| C3 |
Radial Internal Clearance Larger Than Normal (For Spherical Plain Bearings Requiring Maintenance) |
