INA GE25-XL-KLL-B-FA164 Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,805.62 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
25 |
| Dış (D) MM |
52 |
| En (B) MM |
44,5 |
| İç (d) Inch |
0.9843 |
| Dış (D) Inch |
2.0472 |
| En (B) Inch |
1.752 |
| Ağırlık |
0.25 kg
|
Ürün Özellikleri
| Fok |
2LB - İki Labirent Mührü |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
E - High Temp Design Up to +250°C |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
52 |
| Genişlik (b) mm |
34,9 |
| Locking collar total width (B 1) mm |
44,5 |
| Radial Static Load Rating C0r (N) |
7800 |
| Radial Dynamic Load Rating Cr (N) |
14000 |
| Temel statik yük derecesi, radyal (C 0r) |
"7800.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GE..-XL-KLL-B-FA164 |
Suffix description
| XL |
X-Life |
| K |
Conrad (Non-Filling Slot) Type |
| LL |
Labyrinth Seals On Both Sides (L Type Seal - All Parts Of The L Type Seal Are Zinc Plated On All Sides In Order To Improve Corrosion Protection - No Seal Friction) |
| B |
Bearing With Spherical Outer Ring |
| FA164 |
High Temperature Design Up To +250 °C |
