INA GE30-FW-2RS-A Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,052.16 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
30 |
| Dış (D) MM |
55 |
| En (B) MM |
32 |
| İç (d) Inch |
1.1811 |
| Dış (D) Inch |
2.1654 |
| En (B) Inch |
1.2598 |
| Ağırlık |
0.284 kg
|
Ürün Özellikleri
| Fok |
2RS - İki Tarafta Kauçuk Conta |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
55 |
| Radial Static Load Rating C0r (N) |
353000 |
| Width inner ring (B) mm |
32 |
| Radial Dynamic Load Rating Cr (N) |
212000 |
| Temel statik yük derecesi, radyal (C 0r) |
"353000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series G, sealed |
Suffix description
| FW |
Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
| 2RS |
Lip Seals On Both Sides |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
