INA GY1112-KRR-B-AS2/V Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 824.89 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
44,45 |
| Dış (D) MM |
85 |
| En (B) MM |
49,2 |
| İç (d) Inch |
1.75 |
| Dış (D) Inch |
3.3465 |
| En (B) Inch |
1.937 |
| Ağırlık |
0.62 kg
|
Ürün Özellikleri
| Fok |
2F - Y-Rulmanlar için Standart Conta |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
No Special Treatment |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
85 |
| Genişlik (b) mm |
49,2 |
| Radial Static Load Rating C0r (N) |
20400 |
| Radial Dynamic Load Rating Cr (N) |
34500 |
| Temel statik yük derecesi, radyal (C 0r) |
"20400.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GY..-KRR-B-AS2/V |
Suffix description
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| AS2/V |
Bearing Outer Ring With Two Lubrication Holes In Offset Planes |
