INA GYE45-KRR-B-VA-HLA Rulman Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,026.09 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
45 |
| Dış (D) MM |
85 |
| En (B) MM |
49,2 |
| İç (d) Inch |
1.7717 |
| Dış (D) Inch |
3.3465 |
| En (B) Inch |
1.937 |
| Ağırlık |
0.657 kg
|
Ürün Özellikleri
| Fok |
2F - Y-Rulmanlar için Standart Conta |
| Yağlama |
Standart Yağlama |
| Özel Muamele |
Stainless Steel Bearing |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
85 |
| Genişlik (b) mm |
49,2 |
| Radial Static Load Rating C0r (N) |
19400 |
| Radial Dynamic Load Rating Cr (N) |
31500 |
| Temel statik yük derecesi, radyal (C 0r) |
"19400.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GYE..-KRR-B-VA |
Suffix description
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| VA |
Corrosion-Resistant Design Made From High Alloy Rolling Bearing Steel |
| HLA |
Factory Location Code, No Additional Meaning. Can Be Used As Standard |
