INA HFL0606-KF-R-A-L564 Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 556.92 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
6 |
| Dış (D) MM |
10 |
| En (B) MM |
6 |
| Ağırlık |
0.001 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
6 |
| Limiting speed for rotating shaft (n GW) |
23000 |
| Limiting speed for rotating outer ring (n GA) |
13000 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
| Medias description |
Drawn cup roller clutches HFL..-KF-R, with plain or rolling bearing arrangement, plastic springs, knurled outer ring |
Suffix description
| KF |
Plastic Springs |
| R |
Partially Knurled Outer Ring For Assembly In Plastic Housing |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
