INA KR19-X-PP-A Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 783.98 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
8 |
| Dış (D) MM |
19 |
| En (B) MM |
11 |
| İç (d) Inch |
0.315 |
| Dış (D) Inch |
0.748 |
| En (B) Inch |
0.4331 |
| Ağırlık |
0.0285 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Excenterring |
Other Mounting Method |
| Running Surface |
Cylindrical |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
8 |
| Width of the roller stud (B) mm |
32 |
| Basic dynamic load rating, radial (C r w) |
3550 |
| Temel statik yük derecesi, radyal (C 0r) |
4100 |
| Speed on permanent grease lubrication (n D G) |
11000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KR..-PP, with axial guidance, plastic axial plain washers on both sides |
Suffix description
| X |
Cylindrical Running Surface |
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Design Modification |
