INA KR26-PP-A Rulman Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 870.90 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
10 |
| Dış (D) MM |
26 |
| En (B) MM |
12 |
| İç (d) Inch |
0.3937 |
| Dış (D) Inch |
1.0236 |
| En (B) Inch |
0.4724 |
| Ağırlık |
0.058 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Excenterring |
Other Mounting Method |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
10 |
| Width of the roller stud (B) mm |
36 |
| Basic dynamic load rating, radial (C r w) |
5100 |
| Temel statik yük derecesi, radyal (C 0r) |
6500 |
| Speed on permanent grease lubrication (n D G) |
8000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KR..-PP, with axial guidance, plastic axial plain washers on both sides |
Suffix description
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Alteration In Internal Construction. Identical To Old Notation |
