INA KRE26-B Rulman Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,005.94 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
13 |
| Dış (D) MM |
26 |
| En (B) MM |
12 |
| İç (d) Inch |
0.5118 |
| Dış (D) Inch |
1.0236 |
| En (B) Inch |
0.4724 |
| Ağırlık |
0.073 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
10 |
| Genişlik (b) mm |
36 |
| Basic dynamic load rating, radial (C r w) |
5100 |
| Temel statik yük derecesi, radyal (C 0r) |
6500 |
| Speed on permanent grease lubrication (n D G) |
8000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KRE.., with axial guidance via thrust collar or washer, axial plain washers on both sides, with eccentric collar |
Suffix description
| B |
Internal Design Modification, Can Be Used As Standard |
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
