INA KRV16-X-PP-A-NMT Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 885.10 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
6 |
| Dış (D) MM |
16 |
| En (B) MM |
11 |
| İç (d) Inch |
0.2362 |
| Dış (D) Inch |
0.6299 |
| En (B) Inch |
0.4331 |
| Ağırlık |
0.019 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Excenterring |
Other Mounting Method |
| Running Surface |
Cylindrical |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
6 |
| Genişlik (b) mm |
28 |
| Basic dynamic load rating, radial (C r w) |
4850 |
| Temel statik yük derecesi, radyal (C 0r) |
6700 |
| Speed on permanent grease lubrication (n D G) |
3800 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KRV..-PP, with axial guidance, full complement needle roller set, plastic axial plain washers on both sides |
Suffix description
| X |
Cylindrical Running Surface |
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Design Modification |
| NMT |
Hexagon Nut |
