INA KRV35-B Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,079.29 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
16 |
| Dış (D) MM |
35 |
| En (B) MM |
18 |
| İç (d) Inch |
0.6299 |
| Dış (D) Inch |
1.378 |
| En (B) Inch |
0.7087 |
| Ağırlık |
0.177 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Excenterring |
Other Mounting Method |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
16 |
| Genişlik (b) mm |
52 |
| Basic dynamic load rating, radial (C r w) |
12700 |
| Temel statik yük derecesi, radyal (C 0r) |
23400 |
| Speed on permanent grease lubrication (n D G) |
1600 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KRV..-PP, with axial guidance, full complement needle roller set, plastic axial plain washers on both sides |
Suffix description
| B |
Internal Design Modification, Can Be Used As Standard |
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
