INA KRVE22-PP-A Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 982.83 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
13 |
| Dış (D) MM |
22 |
| En (B) MM |
12 |
| İç (d) Inch |
0.5118 |
| Dış (D) Inch |
0.8661 |
| En (B) Inch |
0.4724 |
| Ağırlık |
0.0505 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
10 |
| Genişlik (b) mm |
36 |
| Basic dynamic load rating, radial (C r w) |
6200 |
| Temel statik yük derecesi, radyal (C 0r) |
9300 |
| Speed on permanent grease lubrication (n D G) |
2600 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Yoke type track roller KRVE..-PP-A, full complement needle roller set, with axial guidance, with eccentric |
Suffix description
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Alteration In Internal Construction. Identical To Old Notation |
