INA KWSE25-H-V0-G1 Rulman Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 4,029.27 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
23 |
| Dış (D) MM |
48 |
| En (B) MM |
81,8 |
| İç (d) Inch |
0.9055 |
| Dış (D) Inch |
1.8898 |
| En (B) Inch |
3.2205 |
| Ağırlık |
0.5 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
48 |
| Overall length carriage (L) mm |
81,8 |
| Dynamic load rating, load direction I: compressive load (I C) |
28000 |
| Static load rating, load direction I: compressive load (I C 0) |
67000 |
| Dynamic load rating, load direction II: tensile load (II C) |
26000 |
| Static load rating, load direction II: tensile load (II C 0) |
45000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
28000 |
| Static load rating, Load direction III: lateral load (III C 0) |
47000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| H |
High Carriage |
| V0 |
Little To No Preload |
| G1 |
Precision Class 1 |
