INA KWSE30-V1-G1 Rulman Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 4,818.97 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
28 |
| Dış (D) MM |
90 |
| En (B) MM |
91,4 |
| İç (d) Inch |
1.1024 |
| Dış (D) Inch |
3.5433 |
| En (B) Inch |
3.5984 |
| Ağırlık |
1.2 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
90 |
| Overall length carriage (L) mm |
91,6 |
| Dynamic load rating, load direction I: compressive load (I C) |
40000 |
| Static load rating, load direction I: compressive load (I C 0) |
80000 |
| Dynamic load rating, load direction II: tensile load (II C) |
37800 |
| Static load rating, load direction II: tensile load (II C 0) |
60000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
40000 |
| Static load rating, Load direction III: lateral load (III C 0) |
62000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| V1 |
Slight Preload |
| G1 |
Precision Class 1 |
