INA KWSE45-L-V0-G2 Rulman Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 8,976.08 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
45 |
| Dış (D) MM |
120 |
| En (B) MM |
172,3 |
| İç (d) Inch |
1.7717 |
| Dış (D) Inch |
4.7244 |
| En (B) Inch |
6.7835 |
| Ağırlık |
4.2 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
120 |
| Overall length carriage (L) mm |
174,3 |
| Dynamic load rating, load direction I: compressive load (I C) |
98000 |
| Static load rating, load direction I: compressive load (I C 0) |
236000 |
| Dynamic load rating, load direction II: tensile load (II C) |
89000 |
| Static load rating, load direction II: tensile load (II C 0) |
159000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
93400 |
| Static load rating, Load direction III: lateral load (III C 0) |
168000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Long carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| L |
Long Carriage |
| V0 |
Little To No Preload |
| G2 |
Precision Class 2 |
