INA KWVE30-B-E-V2-G1 Rulman
Fiyatı: 3,247.84 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-B-E-V2-G1 INA |
| Üretici No | 0641227860320 |
| Alternatif Kodu |
KWVE30-B-E-G1-V2 |
| EAN | 4054362994954 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 36,05 |
| Dış (D) MM | 90 |
| En (B) MM | 99 |
| İç (d) Inch | 1.4193 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 3.8976 |
| Ağırlık | 1 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 99 |
| Dynamic load rating (C) | 27500 |
| Static load rating (C 0) | 55000 |
| Static moment rating about X axis (M 0x) | 970 |
| Static moment rating about Y axis (M 0y) | 700 |
| Static moment rating about Z axis (M 0z) | 700 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type |
| B | Standard Carriage, Four-Row, Full Complement Ball Set |
| E | Expanded Design (Carriage Without Screw Threads) |
| V2 | Preload Class 2 |
| G1 | Precision Class 1 |
