INA KWVE30-B-E-V2-G1 Rulman Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,247.84 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
36,05 |
| Dış (D) MM |
90 |
| En (B) MM |
99 |
| İç (d) Inch |
1.4193 |
| Dış (D) Inch |
3.5433 |
| En (B) Inch |
3.8976 |
| Ağırlık |
1 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
90 |
| Overall length carriage (L) mm |
99 |
| Dynamic load rating (C) |
27500 |
| Static load rating (C 0) |
55000 |
| Static moment rating about X axis (M 0x) |
970 |
| Static moment rating about Y axis (M 0y) |
700 |
| Static moment rating about Z axis (M 0z) |
700 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type |
Suffix description
| B |
Standard Carriage, Four-Row, Full Complement Ball Set |
| E |
Expanded Design (Carriage Without Screw Threads) |
| V2 |
Preload Class 2 |
| G1 |
Precision Class 1 |
